Power HD B5S HV Coreless Servo

Specifications

• Torque(6.0V): 16.0 kg-cm (222.2 oz/in)

• Torque(7.4V): 18.0 kg-cm (250.0 oz/in)

• Torque(8.4V): 20.0 kg-cm (277.7 oz/in)

• Speed: 0.065 sec (6.0V) ¦ 0.055 sec (7.4V)¦

• Speed: 0.05 sec (8.4V)

• Operating Voltage: 6.0 ~ 8.4 DC Volts

• Weight: 67.0 g (2.36 oz)

• Bearing Type: Ball Bearing x 2

• Motor Type: Brushless Motor

• Gear Type: Titanium & Steel

• Operating Temperature: -20~60°C

• Working frequency: 1520µs / 333hz

• Size: 41.0 x 20.5 x 38.3 mm ( 1.61 x 0.81 x 1.51 in)
