Dualsky DSXM52030 XM6352DA-26 220kv Competition F3A Motor
Dualsky XM6352DA-26 Competition F3A motor, 220kV
Features
- XM6352DA V4, corresponding to 3000 watts class, suitable for lightweight F3A airplanes and up to 12kg gliders
- New curved magnets. Torque in the middle RPM range is increased by 12% to 15% (compared to DA V3 motor)
- Hollow shaft and lightweight parts, the overall weight is reduced by 7-10%.
- With 3 EZO bearings and precisely balanced rotors, the motors can be maintenance-free up to 1000 flights.
- Optimized rear support bearing (mount)
- The total length of the two types of motor are uniform, the accessories are interchangeable, and they can be replaced seamlessly.
Specification
- RPM/V (KV): 220
- Stator (DxL): 5322
- Weight: 490g
- Ri (mOhm): 43
- Io @ 10V (A): 0.7
- Voltage: 40 V
- Peak Current (W): 75 A
- Peak Power (W): 3000
- Torque (N*M): 4.07
$94.65
Original: $270.44
-65%Dualsky DSXM52030 XM6352DA-26 220kv Competition F3A Motor—
$270.44
$94.65Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Dualsky XM6352DA-26 Competition F3A motor, 220kV
Features
- XM6352DA V4, corresponding to 3000 watts class, suitable for lightweight F3A airplanes and up to 12kg gliders
- New curved magnets. Torque in the middle RPM range is increased by 12% to 15% (compared to DA V3 motor)
- Hollow shaft and lightweight parts, the overall weight is reduced by 7-10%.
- With 3 EZO bearings and precisely balanced rotors, the motors can be maintenance-free up to 1000 flights.
- Optimized rear support bearing (mount)
- The total length of the two types of motor are uniform, the accessories are interchangeable, and they can be replaced seamlessly.
Specification
- RPM/V (KV): 220
- Stator (DxL): 5322
- Weight: 490g
- Ri (mOhm): 43
- Io @ 10V (A): 0.7
- Voltage: 40 V
- Peak Current (W): 75 A
- Peak Power (W): 3000
- Torque (N*M): 4.07
