Dualsky DSXM51747 GA800.11 Brushless Motor 30E 500kv

Dualsky GA800.7 850KV Brushless Motor, 800w, 30E

Features

• Designed for 30E 40E class 3D airplane (Up to 55 inch wingspan)
• Great alternative for a .15-.46ci engine
• New modular light weight structure
• Dualsky 28 poles efficient structure
• Integrated motor mount

Specification

• RPM/V KV: 550
• Weight w/o accessories: 160g
• Outer Diameter: 46 mm
• Length w/ mounts: 42mm
• Length (overall): 74mm
• Diameter of Shaft: 5mm (internal)
• 8mm (output)
• Mounting holes pitch: 52mm to 58mm (D 4.2)
• Slots, Poles: 24, 28
• Idle Current (Io) @10V: 1.3A
• Resistance (Ri): 42.7 mOhm
• Nominal Voltage (V): 22.2V, 6S LiPo
• Peak Power [15s]: 1000W
• Bursts Current [15s]: 42A
• Cruising Power [8 mins]: 500W
• Recommended ESC: XC406ULT
• Propeller:
• 12 x 6 for best efficiency
• 13 x 6.5 for pilots performance
• 14 x 7 for extreme thrust
• Weight of Sports Airplane: Up to 2.2kg
• Weight of 3D Airplane: 1.5kg to 1.8kg
