Dualsky DSXM51662 ECO 2814C 860kv Brushless Motor

The 2814C ECO motor from Dualsky has 860Kv of power. This motor comes with propeller and motor mounts, in addition to gold plugs and screws. ECO V2 has made great improvements in many respects. It has a new electromagnetic design, more competitive performance and efficiency, long-time endurance and is waterproof.

Features

• Motor structure strength increased by 25%
• Classic Dualsky five-spoke back cover with simple lines
• Traditional Dualsky colour matching (silver-black-sliver), anodized and matte finishing
• Optimized stress distribution and strength increased
• High temperature resistant, high toughness epoxy glue
• Motor working life significantly increased by 50% (same load and working environment)
• Optimized heat dissipation ways
• Up to 500V insulation level. The stator is coated with an insulated coating and completely insulated after winding.
• Rust-proof main shaft, coil soak insulation, electrophoresis components and coated magnets make ECO V2 waterproof and have no problem working in wet or rainy environments

Specification

• KV: 860
• Turns: 8.5
• Weight: 105 g
• Dimensions (D x L): 35.2 x 34.2 mm
• Slots & Poles: 12N14P
• Ri (mOhm): 63
• Io @10V: 0.8
• No. of Cells: 3 - 4
• Max. Efficiency Current: 18 A
• Max. Burst Current: 30 A
• Max. Power (15S): 480 W
• Max. Torque (N*M): 0.4
• Shaft Diameter: 5 mm
• Mounting Holes Pitch: 19/19
• Input Connectors: GC3.5
• Recommended ESC: XC-45-LITE or XC4018BA
• Propeller: 3S: 14x8.5E, 13x8E / 4S: 12x4E, 10x5E
• Class: .10 - .15 Class
